Aramid Fabric Kevlar Cloth

Applications: military, aerospace, special fields

Aramid Cloth

Aramid Cloth (Kevlar Fabric)

Aramid cloth, also known as Kevlar fabric, is a strong and durable synthetic fabric made from aramid fibers. It has a high strength-to-weight ratio, making it a popular choice for applications where strength is required without adding weight. It is commonly used in protective clothing, body armor, sports equipment, and the aerospace and automotive industries due to its resistance to abrasion, cut, impact, and heat.

We produce, develop, and sell aramid fabrics, providing a variety of process products such as plain, twill, woven, and plain weave. Our factory produces generic aramid fabrics with specifications ranging from 60g to 500g in weight and 0.1mm to 0.8mm in thickness. Our factory supports customized process services, OEM & ODM, and all our products provide free sample services in A4 size.

About Kevlar Aramid Fabric

Strong Kevlar Fabric

Kevlar Aramid Fabric is a highly durable and strong synthetic material.

Versatile Kevlar Cloth

Kevlar Aramid Fabric offers excellent properties for various applications.

Heat-Resistant Material

Kevlar Aramid Fabric is a heat-resistant material commonly used in high-temperature applications.

Specification Weight(g/m2) Yarn Specification Width(CM) Weave Style 1 Weave Style 2 Thickness(mm) Warp Density Weft Density Meter length can be customized Rewind inner diameter
PT001 400 3000D 30-320 Plain Weave Twill Weave
0.55+0.1
 61 51 50-200 3\4\6 inch
PT002 300 3000D 30-320 Plain Weave Twill Weave
0.45+0.1
 5+1 41 50-200 3\4\6 inch
PT003 200 1500D 30-320 Plain Weave Twill Weave
0.26+0.05
 61 5.5+1 50-400 3\4\6 inch
PT004 220 1500D 30-320 Plain Weave Twill Weave
0.26+0.05
 61 61 50-400 3\4\6 inch
PT005 240 1500D 30-320 Plain Weave Twill Weave
0.28+0.05
 61 6.5+1 50-400 3\4\6 inch
PT006 200 1000D 30-320 Plain Weave Twill Weave
0.25+0.05
 91 91 50-400 3\4\6 inch
PT007 270 1000D 30-320 Plain Weave Twill Weave
0.32+0.05
 131 111 50-400 3\4\6 inch
PT008 180 1000D 30-320 Plain Weave Twill Weave
0.23+0.05
 91 7.51 50-400 3\4\6 inch
PT009 145 800D 30-320 Plain Weave Twill Weave
0.18+0.05
 81
8+1
 50-400 3\4\6 inch
PT010 340 1500D 30-320 Plain Weave Twill Weave
0.42+0.1
 111 9+1 50-400 3\4\6 inch
PT011 420 3000D 30-320 Plain Weave Twill Weave
0.6+0.1
 61 5+1 50-200 3\4\6 inch
PT012 230 202 30-300   Twill Weave
0.5+0.1
 20+2 14+2 50-400 3\4\6 inch
PT013 500 1500Ply 30-320 Plain Weave Twill Weave
0.7+0.1
 71 51 50-400 3\4\6 inch
PT014 60 200D 30-320 Plain Weave Twill Weave
0.1+0.03
 141 131 50-400 3\4\6 inch
PT015 80 400D 30-320 Plain Weave Twill Weave
0.14+0.03
 91 91 50-400 3\4\6 inch
PT016 230 204 30-300 Plain Weave Twill Weave
0.45+0.1
 101 81 50-400 3\4\6 inch
PT017 240 Aramid filament interwoven 30-300 Plain Weave
0.28+0.03
 4+0.5 2+0.5 50-400 3\4\6 inch
PT018 280 Single hot melt 30-300 Plain Weave
0.15+0.03
 851 15 50-400 3\4\6 inch
PT019 100 400D 30-320 Plain Weave Twill Weave
0.15+0.03
 91 131 50-400 3\4\6 inch
PT020 100 600D 30-320 Plain Weave Twill Weave
0.16+0.03
 91 6.5+1 50-400 3\4\6 inch
PT021 120 600D 30-320 Plain Weave Twill Weave
0.54+0.03
 91 9+1 50-400 3\4\6 inch
PT022 300 1500D+2000D 30-320 Plain Weave Twill Weave   71 81 50-400 3\4\6 inch
PT023 460 3000D+3000D 30-320   Twill Weave   61 61 50-400 3\4\6 inch
