Aramid Prepreg

Aramid Prepreg

Aramid prepreg is a composite material made by impregnating aramid fibers (as the reinforcement substrate) with matrix resins such as epoxy resin and phenolic resin. It integrates the high strength and high temperature resistance of aramid fibers with the insulating properties of resins.

After curing, it features a dense structure and excellent mechanical stability, capable of maintaining reliable insulation performance in complex industrial environments. Thus, it plays a crucial role in key insulation scenarios of various industrial equipment, adapting to the operating condition requirements of different devices.

Features

  • Retains the core mechanical properties of aramid fibers: high specific strength, high modulus, and impact resistance.
  • B-stage resin endows processability including cuttability and thermoformable/moldable shaping; forms a rigid structure after curing, with no loosening or deformation.
  • Integrates the reinforcing properties of fibers with the forming/bonding properties of resins, serving as a key link connecting aramid raw materials to final products.

Specifications of the resin used in aramid prepregs

Model Resin Type Curing Temperature Product Features Applicable Industries
PR100E Solvent-based epoxy resin 125-130℃ General purpose Sports goods, 3C products
PR210E Hot-melt epoxy resin 125-130℃ General purpose Sports goods, industry, aviation
PR211E Hot-melt epoxy resin 125-130℃ Low resin loss, impact resistance Sports goods, 3C products
PR212E Hot-melt epoxy resin 125-130℃ Low resin loss, impact resistance, high viscosity Sports goods, 3C products
PR219E Hot-melt epoxy resin 125-130℃ Low resin loss, impact resistance, high transparency Sports goods, industry, aviation
PR320E Hot-melt epoxy resin 80-150℃ Fast curing Sports goods, industry, 3C products
PR420E High Tg epoxy resin 200-210℃ Low resin loss, high Tg 170℃, post-curable Sports goods, industry, aviation, aerospace
PR430E High Tg epoxy resin 210-240℃ Low resin loss, high Tg 200℃ Sports goods, industry, aviation, aerospace
PR400P Phenolic resin 200-210℃ Flame retardant, high temperature resistance, high Tg Bulletproof helmets, armor plates

Aramid prepreg product forms

Classification Morphological Description Fiber Weight FAW Resin Content RC% Customization Instructions Applicable Processes
PTPREG™ UD, plain weave, twill weave, pattern woven prepreg (natural color/colored) 40-630g 10-50% Fabric width 30-1270mm Tube winding, molding, hot pressing, etc.
PTMC™ Pre-impregnated chopped strands (natural color/colored) – 30-50% Chopped strand length 3-120mm Molding, hot pressing, etc.
PTTOW™ Pre-impregnated continuous tow (natural color/colored) – 30-50% Linear density 200-150000 Filament winding

Application

Military protection

Bulletproof Products

Composite materials

Aerospace

Communication Cable

High-end Industrial Products

Mobile Phone Case

Sporting Goods
